Understanding Slate Grades and Thickness for Roofs

Why slate grades matter

Slate is not one material. A Welsh slate quarried at Bethesda, a Spanish slate from Galicia and a Chinese slate shipped in bulk may all be sold as "roofing slate", yet their behaviour on your roof over fifty years could not be more different. Grading exists because slate is a natural stone with natural variation, and the trade has always needed a shorthand way of saying how sound, how thick and how durable a particular slate is likely to be.

Get the grade right and you can expect a roof that outlives you. Get it wrong and you may be replacing it within twenty years — or sooner. It is one of the few places on a building where paying properly for the material saves money in the long run.

The traditional British grades explained

For most of the last two centuries, British slate was sold under three simple headings.

Best — the soundest, thickest, most carefully dressed slates, free from knots and flaws. Reserved for the most exposed elevations, the lowest pitches and the most important buildings.
Seconds — slightly smaller or less perfectly finished, but still reliable. The workhorse grade for general roofing.
Thirds (also called "rustics" or, in the West Country, "raining" slates) — thin, short and often irregular. Good enough for sheds, lean-tos and out-of-sight work, but not for a house you intend to keep dry for a century.

Alongside these, the Welsh trade used named sizes that bundled a length, a width and a thickness together — Duchess, Countess, Princess, Queen and Empress among them. A Duchess was a large, substantial slate; a Countess was smaller and lighter. Ordering by name told the quarry exactly what you wanted, which is why the old names still appear in conversations about heritage work.

Thickness: the quiet measure of quality

Thickness is the single most useful indicator you can hold in your hand. Traditionally measured in inches from around 3/16 inch to 3/8 inch and beyond, slates are now specified in millimetres, with much imported material arriving at 4mm to 6mm and good British slate commonly at 6mm to 9mm for the larger sizes. Thicker slate resists wind uplift, frost damage and the occasional clumsy foot on the roof; thinner slate is lighter on the structure but far less forgiving.

Bear in mind what that weight means. A natural slate roof typically imposes somewhere between 25 and 45 kg per square metre, and the heavier end needs adequate rafters, correctly sized battens and a batten spacing that suits the slate gauge. Nails should be roughly two and a half times the slate thickness, in copper or stainless steel rather than galvanised — the fixings often outlive the slate, and it is a shame to lose a good roof to a bad nail.

What BS EN 12326 designations tell you

European standard BS EN 12326-1 tests slate for water absorption, carbonate content, resistance to sulphur dioxide and thermal cycling. The resulting designation — a string of letters and numbers — describes how the stone should behave in service. Ask your merchant for it, and ask what the declared nominal thickness is, because the standard covers thickness tolerance as well as performance.

The important caveat is that the standard is a minimum benchmark, not a quality guarantee. A slate can pass every test and still be a poor long-term choice compared with a proven British stone. Treat the designation as a floor, not a finish line, and be wary of very cheap material marketed loosely as "best grade" when no evidence supports the claim.

Pitch, exposure and the structure beneath

Grading is only half the specification. BS 5534 links the slate you choose to the pitch of the roof, the size of the slate, the headlap and the site's exposure to wind-driven rain.

Larger slates allow more headlap and permit a lower pitch.
Sheltered sites in lowland Britain may cope with pitches from around 20 to 22.5 degrees, subject to the standard.
Coastal, upland and otherwise exposed locations demand more headlap, a steeper pitch, or both.
Thicker slates in the same size give a heavier, more robust covering better suited to severe exposure.

A practical rule: if you are at the lower end of the permitted pitch range, move up a grade in thickness rather than down a price bracket. It is far cheaper than returning to fix a leaking roof.

Heritage properties and sensitive repairs

On listed buildings and in conservation areas, the aim is rarely to re-roof from scratch. Usually it is to repair, matching what is there in size, thickness, colour and texture. Reclaimed slate sorted by thickness is the traditional answer, supplemented by new slate from a sympathetic source where the original is unavailable.

Resist the temptation to strip a sound historic roof because a handful of slates have slipped. Localised repairs, re-dressing of laps and renewal of leadwork at valleys, ridges and hips often buy decades more service. Discuss the approach with your conservation officer early, and be prepared to justify your material choice — they will usually welcome a well-argued case for honest, matched slate over a cheap and cheerful substitute.

Before you order anything, ask three questions: what grade is this, what is the nominal thickness, and what evidence backs the claim? A supplier who answers clearly is worth the small premium. A supplier who cannot is telling you something useful too.
